Material: 1.0045 – S355JR

Description:

Unalloyed mild steel with guaranteed minimum mechanical values
With special cold formability also 1.0551; S355JRC
Easily weldable

Applications:

simple applications in mechanical engineering

Stahlwerk Augustfehn Werkstoff 1.0045 - C45
  • DIN EN Bezeichnung: S355JR
  • USA AISI(SAE): -
  • Frankreich AFNOR: -
  • British Standard: -

Technical characteristics

Chemical composition (acc. DIN EN 10025-2 (10/2019))

Mass fraction in %

C [%]

max. 0.24

Si [%]

max. 0.55

Mn [%]

max. 1.6

Cr [%]

max. 0.29

Cu [%]

max. 0.55

P [%]

max. 0.035

S [%]

max. 0.035

Mo [%]

max. 0.11

N [%]

max. 0.012

Ni [%]

max. 0.42

Mechanical properties

For more information on the mechanical properties, please refer to the following product datasheet for download.

Download
