Material: 1.2314 – X47CrMo15

Description:

Alloyed tool steel

Applications:

tools for plastic industry

Stahlwerk Augustfehn Werkstoff 1.2314 - Ck60
  • DIN EN Bezeichnung: X47CrMo15
  • USA AISI(SAE): -
  • Frankreich AFNOR: -
  • British Standard: -

Technical characteristics

Mass fraction in %

C [%]

min. 0.45

max. 0.5

Si [%]

min. 0.3

max. 0.5

Mn [%]

min. 0.3

max. 0.5

Cr [%]

min. 14

max. 15

P [%]

max. 0.035

S [%]

max. 0.035

Mo [%]

min. 0.2

max. 0.3

Mechanical properties

For more information on the mechanical properties, please refer to the following product datasheet for download.
