Material: 1.2327 – 86CrMoV7

Description:

Tool steel for cold work with high wear resistance and low crack sensitivity

Applications:

Standard cold rolled steel for rolls of all dimensions, backup and work rolls, straightening rolls, journals, shafts, roller bodies.

Stahlwerk Augustfehn Werkstoff 1.2327 - X47CrMo15
  • DIN EN Bezeichnung: 86CrMoV7
  • USA AISI(SAE): -
  • Frankreich AFNOR: -
  • British Standard: -

Technical characteristics

Mass fraction in %

C [%]

min. 0.83

max. 0.9

Si [%]

min. 0.15

max. 0.35

Mn [%]

min. 0.3

max. 0.45

Cr [%]

min. 1.6

max. 1.9

P [%]

max. 0.03

S [%]

max. 0.03

Mo [%]

min. 0.15

max. 0.3

V [%]

min. 0.05

max. 0.15

Mechanical properties

For more information on the mechanical properties, please refer to the following product datasheet for download.

Download
