Material: 1.2367 – X38CrMoV5-3

Description:

Alloyed tool steel

Applications:

Tools for hot work, dies

Stahlwerk Augustfehn Werkstoff 1.2367 - X40CrMoV5-1
  • DIN EN Bezeichnung: X38CrMoV5-3
  • USA AISI(SAE): -
  • Frankreich AFNOR: -
  • British Standard: -

Technical characteristics

Chemical composition (acc. DIN EN ISO 4957 (11/2018)))

Mass fraction in %

C [%]

min. 0.35

max. 0.4

Si [%]

min. 0.3

max. 0.5

Mn [%]

min. 0.3

max. 0.5

Cr [%]

min. 4.8

max. 5.2

P [%]

max. 0.03

S [%]

max. 0.02

Mo [%]

min. 2.7

max. 3.2

V [%]

min. 0.4

max. 0.6

Mechanical properties

For more information on the mechanical properties, please refer to the following product datasheet for download.

Download
