Material: 1.2743 – 60NiCrMoV12-4

Description:

Air-hardening high-performance tool steel for cold work

Applications:

Shear blades for scrap shears, dies, embossing tools, punches, forging saddles.

Stahlwerk Augustfehn Werkstoff 1.2743 - X153CrMoV12
  • DIN EN Bezeichnung: 60NiCrMoV12-4
  • USA AISI(SAE): -
  • Frankreich AFNOR: -
  • British Standard: -

Technical characteristics

Mass fraction in %

C [%]

min. 0.55

max. 0.6

Si [%]

min. 0.3

max. 0.5

Mn [%]

min. 0.5

max. 0.8

Cr [%]

min. 1

max. 1.3

P [%]

max. 0.035

S [%]

max. 0.035

Mo [%]

min. 0.3

max. 0.4

V [%]

min. 0.07

max. 0.12

Ni [%]

min. 2.7

max. 3

Mechanical properties

For more information on the mechanical properties, please refer to the following product datasheet for download.

Download
