Material: 1.2766 – 35NiCrMo16

Description:

Tool steel for hot work, extreme toughness with high tensile strength

Applications:

Hot rolled rings, dies, inner bushings, press dies

Stahlwerk Augustfehn Werkstoff 1.4034 - X46Cr13
  • DIN EN Bezeichnung: 35NiCrMo16
  • USA AISI(SAE): -
  • Frankreich AFNOR: -
  • British Standard: -

Technical characteristics

Mass fraction in %

C [%]

min. 0.32

max. 0.38

Si [%]

min. 0.15

max. 0.3

Mn [%]

min. 0.4

max. 0.6

Cr [%]

min. 1.2

max. 1.5

P [%]

max. 0.035

S [%]

max. 0.035

Mo [%]

min. 0.2

max. 0.4

Ni [%]

min. 3.8

max. 4.3

Mechanical properties

For more information on the mechanical properties, please refer to the following product datasheet for download.

Download
