Material: 1.7701 – 52CrMoV4

Description:

Alloyed stainless steel

Applications:

Spring steel for highly stressed components in vehicle construction

Stahlwerk Augustfehn Werkstoff 1.7701 - 50CrMo4
  • DIN EN Bezeichnung: 52CrMoV4
  • USA AISI(SAE): -
  • Frankreich AFNOR: -
  • British Standard: -

Technical characteristics

Chemical composition (acc. DIN EN 10089 (04/2003))

Mass fraction in %

C [%]

min. 0.48

max. 0.56

Si [%]

max. 0.4

Mn [%]

min. 0.7

max. 1.1

Cr [%]

min. 0.9

max. 1.2

S [%]

max. 0.025

Mo [%]

min. 0.15

max. 0.3

V [%]

min. 0.1

max. 0.2

Mechanical properties

For more information on the mechanical properties, please refer to the following product datasheet for download.

Download
